Use the following procedure to make adjustments in position control for the OMNUC G Series.
Write the data to EEPROM in the parameter write mode.
Increase the Position Loop Gain (Pn010),
but not so much that it causes overshooting.
Reduce the Speed Loop Gain (Pn011).
Start of adjustment
Disable realtime autotuning (Pn021 = 0).
Set each parameter to the values in
Parameter Settings for Different Applications.
Operate with a normal operating pattern and load.
Positioning time and other operational performance satisfactory?
Ye s
No
End of adjustment
Never make extreme adjustment or
changes to settings. Doing so will result
in unstable operation and may lead to
injuri
es. Adjust the gain in small
increments while checking Servomotor
operation.
Increase the Speed Loop Gain (Pn011),
but not so much that it causes hunting when the servo is locked.
Reduce the Speed Loop Integration Time Constant (Pn012),
but not so much that it causes hunting when the servo is locked.
Ye s
No
Does hunting (vibration) occur when the Ser
vomotor is rotated?
End of adjustment
Increase the Speed Loop Integration Time
Constant (Pn012).
If vibration does not stop no matter how many times
you perform adjustments, or if positioning is slow:
Increase the Torque Command Filter Time
Constant (Pn014).
Set the Notch Filter 1 Frequency (Pn01D) and
the Notch Filter 2 Frequency (Pn028)
to the frequency of a vibrating application.
To Next Page
