2-10
2-1 Standard Models
2
Standard Models and Dimensions
Decelerators for 1,000-r/min Servomotors
Note1. The standard models have a straight shaft.
Note2. Models with a key and tap are indicated with "J" at the end of the model number
(the suffix shown in the box). (Example: R88G-HPG32A05900TBJ)
Specifications
Model
Motor
capacity
Gear ratio
900 W
1/5 R88G-HPG32A05900TB
1/11 R88G-HPG32A11900TB
1/21 R88G-HPG50A21900TB
1/33 R88G-HPG50A33900TB
2 kW
1/5 R88G-HPG32A052K0TB
1/11 R88G-HPG50A112K0TB
1/21 R88G-HPG50A212K0TB
1/25 R88G-HPG65A255K0SB
3 kW
1/5 R88G-HPG50A055K0SB
1/11 R88G-HPG50A115K0SB
1/20 R88G-HPG65A205K0SB
1/25 R88G-HPG65A255K0SB
4.5 kW
1/5 R88G-HPG50A054K5TB
1/12 R88G-HPG65A127K5SB
1/20 R88G-HPG65A204K5TB
6 kW
1/5 R88G-HPG65A057K5SB
1/12 R88G-HPG65A127K5SB
