Remove the Main Module
Servicing the Main Module 93
5.
Pull the main module halfway out of the server.
6.
Press the levers back together, toward the center of the main module.
This will keep the levers from getting damaged when you pull the main module out.
7.
Remove the main module completely from the server.
8.
Press down on the green button at the top of the cover to disengage the cover
from the main module, and push the cover toward the rear of the module as you
lift the cover up and away from the chassis.
9.
Determine your next step.
