Parker AC30 User Manual

AC30 series User’s Manual
Frames D, E, F, G, H, J, K including AC30P & AC30D
HA501718U002 Issue 7
Compatible with Firmware Version 1.12 onwards (AC30P & AC30D Version 2.12 onwards)
2016 © Parker Hannin Manufacturing Limited.
All rights strictly reserved. No part of this document may be stored in a retrieval system, or transmitted in any form
or by any means to persons not employed by a Parker Hannin Manufacturing Limited company without written
permission from Parker Hannin Manufacturing Ltd. Although evry efford has been taken to ensure the accuracy
of this document it may be necessary, without notice, to make amendments or corect omissions Parker Hannin
Manufacturing Limited cannot accept responsibility for damage, injury, or expenses resulting thereform.
WARRANTY
The general terms and conditions of sale of goods and/or services of Parker Hannin Europe Sàrl, Luxembourg,
Switzerland Branch, Etoy, apply to this contract unless otherwise agreed. The terms and conditions are available
on our website: www.parker.com/termsandconditons/switzerland
Parker Hannin Manufacturing Limited reserved the right to change the content and product specication without
notice.

Parker AC30 Specifications

General

Protection Rating	IP20
Series	AC30
Type	Variable Frequency Drive
Overload Capacity	150% for 60 seconds
Cooling Method	Fan Cooled
Communication Protocols	CANopen
Power Range	0.75 to 250 kW (1 to 350 hp)
Switching Frequency	2kHz to 16kHz
Safety	Safe Torque Off (STO)
Output Current	Model Dependent
Power Rating	0.75 to 250 kW (1 to 350 hp)
Efficiency	>97%
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overheating
Dimensions	Model Dependent
Weight	Model Dependent
Operating Temperature	-10°C to +40°C
Output Voltage	0 to Input Voltage
