Rotary Feeder Separator Pin Settings
The position of the rotary feeder separator pins is based on the type of material you are running. Use this
table for reference when adjusting the separator pins.
Material Type Pins
Single Sheet (#10, A4, half-fold non-glossy, half-fold glossy) inner fuly in (toward stack)
Folded, perfume inner fuly in (toward stack)
BRE inner fuly in (toward stack)
Booklet (thick .125" max) all pins fully out (away from stack)
Booklet (thin) inner fully in (toward stack)
Operator Adjustments
Pitney Bowes Epic v3.1 (ZVE0) Operator Guide May, 2018 Page 129 of 328
