Enclosure Specifications
Measurements Minimum Maximum
Length 3.0" (76 mm) 8.5" (216 mm)
Width 5.5" (140 mm) 12.0" (305 mm)
Total Enclosure Thickness -
Speed Reduced
.0025" (0.064 mm) .125" (3.2 mm)
Total Enclosure Thickness -
Max Speed
.0032" (0.81 mm) .10" (2.54 mm)
l Enclosure dimensions should not vary more than +/- .03125" (1 mm).
l Enclosure curl or twist should not exceed .125” (3 mm) when enclosure is placed on a flat surface.
Folded Enclosure Specifications
l Folds that result in an even overall thickness of enclosure will give the best feeding performance.
l Folds that are made parallel to the paper grain direction are preferred. This will result in a cleaner,
straighter fold with less thickness increase at the fold.
l Cannot feed "Z" folds.
l Closed end first (see diagram)
l Folds should be sharply creased, flat, and free of edge curl(see diagram).
Curl at Fold
Specifications
Pitney Bowes Epic v3.1 (ZVE0) Operator Guide May, 2018 Page 301 of 328
