User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
The MED Location Configuration and LLDP MED Port Location Table screens in Figure 4-12-22 and Figure 4-12-23 appear.
Figure 4-12-22: MED Location Configuration Page Screenshot
The page includes the following fields:
Object Description
• Ports
Select port for this drop down list.
• Location Coordinate
A string identifying the Location Coordinate that this entry should belong to.
A string identifying the Location Civic Address that this entry should belong to.
• Location ESC ELIN
A string identifying the Location ESC ELIN that this entry should belong to.
Button
: Click to apply changes.
