Planmeca Compact i E-1
Chapter
Technical Manual
E PREVENTIVE MAINTENANCE
NOTE The preventive maintenance should be performed once a year by a qualified
service technician.
1 DELIVERY ARMS
OP delivery arm
• Arm friction. Adjust if needed, refer to section 1.2 “Adjusting friction of the OP delivery arm
joints” on page F-2.
• Arm balance. Adjust if needed, refer to section 1.3 “Adjusting balance of the OP delivery
arm” on page F-3.
Side delivery arm
• Arm frictions. Adjust if needed, refer to sections 1.5 “Adjusting the side delivery arm base
joint friction” on page F-10, 1.6 “Adjusting the friction of the side delivery arm joint” on
page F-10, 1.7 “Adjusting the side delivery arm instrument console friction” on page F-11
and 1.8 “Adjusting the lifting friction of the side delivery arm” on page F-11.
2SUCTION ARMS
Ergo suction arm
• Arm friction. Adjust if needed, refer to section 1.10 “Adjusting friction of the ergo suction
arm” on page F-15.
Adjustable suction arm
• Arm friction. Adjust if needed, refer to section 1.11 “Adjusting friction of the adjustable suc-
tion arm” on page F-15.

Planmeca Compact I Specifications

General

Spittoon	Yes
Operating Light	LED
Imaging Technology	Digital
X-ray Tube Voltage	60-70 kV
X-ray Tube Current	7 mA
Focal Spot Size	0.8 mm
Exposure Time Range	3.2 s
Power Supply	50/60 Hz
