Planmeca Compact I User Manual

Chapter E - PREVENTIVE MAINTENANCE
E-4 Planmeca Compact i
CHAIR
Technical Manual
7CHAIR
Backrest motor
• Operation check.
• Clean and grease the worm screw.
Emergency switches
• Operation check.
Upholsteries
• Condition check.
• Upholsteries are firmly in place. The screws of the seat upholstery are tightened.
8 SUCTION SYSTEM
Suction tubes
• Open and clean the suction nozzles.
• Tube condition check.
Coarse filter
• Condition check. Replace if needed.
Amalgam collector
• Condition check. Replace if needed.
Microvac II suction system
• Change the middle bottom membrane.
• Change the bottom drain membrane.
• Change the pressure balancing membrane.
• Check the rubber sealing.
Other suction systems
• Refer to the manufacturer’s instructions.

Planmeca Compact I Specifications

General

Spittoon	Yes
Operating Light	LED
Imaging Technology	Digital
X-ray Tube Voltage	60-70 kV
X-ray Tube Current	7 mA
Focal Spot Size	0.8 mm
Exposure Time Range	3.2 s
Power Supply	50/60 Hz
