Planmeca Compact I User Manual

Planmeca Compact i G-1
Chapter
Technical Manual
G PARTS REPLACEMENT & REPAIR
1REMOVING COVERS
Cuspidor door
a) Open the cuspidor door.
b) Release the door opening limiter by unscrewing the M4x8 DIN 912 screw.
c) Lift the console arm side of the cuspidor top cover, unscrew the attachment screw and
remove the door joint sleeve.
d) Remove the cuspidor door by tilting it away from the cuspidor.
e) Assemble the cuspidor door into position in reverse order.
Cuspidor cover
a) Remove the side cover plate from the side of the cuspidor by pulling it away from the
cuspidor.
b) The cuspidor cover is attached to the cuspidor with Velcro tapes and attachment pins. First
detach the cover at the chair adapter side of the cuspidor by pulling it outwards. Then pull the
cover outwards at the other side of the cuspidor (see picture on the next page).
c) Assemble the cuspidor cover into position in reverse order.

Planmeca Compact I Specifications

General

Spittoon	Yes
Operating Light	LED
Imaging Technology	Digital
X-ray Tube Voltage	60-70 kV
X-ray Tube Current	7 mA
Focal Spot Size	0.8 mm
Exposure Time Range	3.2 s
Power Supply	50/60 Hz
