Chapter A - GENERAL & TECHNICAL DATA
Planmeca Compact i A-3
TECHNICAL SPECIFICATIONS
Technical Manual
3 TECHNICAL SPECIFICATIONS
Original manufacturer
PLANMECA Oy, Asentajankatu 6, 00880 Helsinki, FINLAND
phone: +358 20 7795 500, fax: +358 20 7795 555, www.planmeca.com
Colours
Painted parts: RAL-9016
Upholstery colours: please consult your dealer for availability
Mechanical dimensions
Installed: (H x D x W) 1210mmx963mmx1990mm (see template for details)
Weight
≈130 kg (287 lbs)
Temperatures and Humidity
Operating: +15°C to +35°C, non condensing humidity from 20% to 75%
Storage: 0°C to +50°C, non condensing humidity from 20% to 75%
Mains voltage and frequency
Mains voltage setting Fuse rating & type
100V~ Wickmann no. 195, 12.5 A, slow blow
115V~ Wickmann no. 195, 12.5 A, slow blow
220-240V~ T6.3A, slow blow
Mains frequency 50 or 60 Hz
Power consumption
Idle unit: ≤ 250VA (unit not in use, OP-light turned on)
Typical average: ≈ 350 VA (during patient treatment)
Maximum: ≥ 1200 VA (at maximum rated mains voltage, both chair motors
running)
Electrical classification
Class I, type B
Chair lift- and backrest motors’ operation:
Intermittent operation, ED 8%, 25 sec "ON", 300 sec. "OFF"
Water supply
Pressure range: min. 300kPa (45 psi), max. 900 kPa (130 psi)
Flow rate: ≤ 4 l/ min (maximum consumption at any instance)
Quality: hardness; ≤ 8 °dH (1°dH= 20mg Ca/ 3 liter water)
Connection: 1/4”
