Chapter A - GENERAL & TECHNICAL DATA
A-4 Planmeca Compact i
TECHNICAL SPECIFICATIONS
Technical Manual
Air supply
Pressure range: min. 550 kPa (80 psi), max. 900 kPa (130 psi)
Flow rate: ≥ 55 litres / minute (maximum consumption at any instance)
Air quality: medical grade, dry and oil-free
Connection: 1/4”
Suction connection
Vacuum: ≥ 150 mbar
Flow rate: ≥ 550 l/ min
Connection: 25 mm (3/4”)
Drain connection
Capacity: min. 10 l/min
Connection: 25 mm (3/4”)

Planmeca Compact I Specifications

General

Spittoon	Yes
Operating Light	LED
Imaging Technology	Digital
X-ray Tube Voltage	60-70 kV
X-ray Tube Current	7 mA
Focal Spot Size	0.8 mm
Exposure Time Range	3.2 s
Power Supply	50/60 Hz
