Chapter E - PREVENTIVE MAINTENANCE
Planmeca Compact i E-5
OPERATING LIGHT
Technical Manual
9OPERATING LIGHT
• Clean the protective fascia.
• Operating light is in focus.
• Light is not turning with the arm.
• Check the voltage.
10 CLEAN WATER SYSTEM
• Operation check.
