Chapter G - PARTS REPLACEMENT & REPAIR
Planmeca Compact i G-21
ELECTRICAL PARTS REPLACEMENT
Technical Manual
5.2 Replacing fuses
WARNING
Always replace fuses with the same type and rating.
Ratings for Mains Fuse Neutral (F11) and Mains Fuse Live (F12)
NOTE The mains fuse ratings depend on the selected voltage setting.
Fuse Panel
Code
Fuse Description Fuse Rating & Type
F5 Operating light fuse T6.3AL, slow blow
F6 Separator 24V~ fuse T8AL, slow blow
F7 Water heater 24V~ fuse T6.3AL, slow blow
F8 Syringe heater 24V~ fuse T6.3AL, slow blow
F9 Electronics +24V Fuse A T4AL, slow blow
F10 Electronics +24V Fuse B T4AL, slow blow
Mains
Voltage
Setting
Fuse Rating & Type
100V~ Schurter T12.5A, slow blow,
0034.3128
115V~ Schurter T12.5A, slow blow,
0034.3128
220-240V~ T6.3A, slow blow

Planmeca Compact I Specifications

General

Spittoon	Yes
Operating Light	LED
Imaging Technology	Digital
X-ray Tube Voltage	60-70 kV
X-ray Tube Current	7 mA
Focal Spot Size	0.8 mm
Exposure Time Range	3.2 s
Power Supply	50/60 Hz
