Planmeca Compact I User Manual

Chapter C - SERVICE MODE
Planmeca Compact i C-17
SERVICE MODE DETAILED DESCRIPTION
Technical Manual
2 SERVICE MODE DETAILED DESCRIPTION
The following pages contain detailed information about the service modes, giving useful infor-
mation on how to use and interpret the information available. Reading this chapter gives a
good understanding of the unit’s control system. Used abbreviations are explained in the
beginning of this manual.
Underlined number or values in the heading texts are factory default values.
2.1 MAIN control system related service modes
n.0 Disable programming and limit micromotor speed
(For educational establishment use.) In this mode the programming of the instrument, unit
and/or chair settings can be disabled, and the micromotor power can be limited to 50% of the
maximum speed.
The following settings are possible. The factory default is 0 (zero).
instrument
settings
disabled
unit settings
disabled
chair settings
disabled
micromotor
speed limited
0
1x
2x
3x x
4x
5x x
6xx
7x x x
8x
9x x
10 x x
11 x x x
12 x x
13 x x x
14 x x x
15xxxx

Planmeca Compact I Specifications

General

Spittoon	Yes
Operating Light	LED
Imaging Technology	Digital
X-ray Tube Voltage	60-70 kV
X-ray Tube Current	7 mA
Focal Spot Size	0.8 mm
Exposure Time Range	3.2 s
Power Supply	50/60 Hz
