Chapter C - SERVICE MODE
Planmeca Compact i C-27
SERVICE MODE DETAILED DESCRIPTION
Technical Manual
2.4 Control panel related service modes
n 45 Show control panel type/AUX input for branch 1 (n = -, 0, 1,
2, 3)
This service mode shows the type of the control panel connected to the MCB branch 1 (nor-
mally the dentist's console control panel). A dash (-) indicates either that no control panel is
connected to this branch, the cable to the panel is loose or faulty, or that the panel itself does
not respond. The numbers 0-3 show that the panel is communicating with the MCB. 0 =
nurse’s panel, 1 = doctor’s panel, 2 = nurse’s plus panel, 3 = doctor’s plus panel.
n 46 Show control panel type/AUX input for branch 2 (n = -, 0, 1,
2, 3)
This service mode shows the type of the control panel connected to the MCB branch 2. See
explanation above.
n 47 Show control panel key code for branch 1 (n.n)
This service mode shows which key is pressed on the control panel connected to MCB
branch 1 (normally the dentist's console control panel). The left side digit (of the decimal
point) indicates the row, the right side digit indicates the column.
n 48 Show control panel key code for branch 2 (n.n)
This service mode shows which key is pressed on the control panel connected to MCB
branch 2. See explanation above.
n 49 Display test
This service mode turns on all individual LEDs and display segments on the control panel(s).
Can be used to check that all displays work properly.
