Planmeca Compact I User Manual

Planmeca Compact i Dental Unit TOC - 5
TABLE OF CONTENTS
Technical Manual
9.2 Replacing OP delivery arm gas spring..................................................... G-43
9.3 Replacing the whole OP delivery arm...................................................... G-44
Chapter H FOOT CONTROL
1 PARTS REPLACEMENT & REPAIR ............................................ H-1
1.1 Removing foot control cover .......................................................................H-1
1.2 Replacing chair control springs...................................................................H-2
1.3 Replacing foot control PCB.........................................................................H-3
1.4 Replacing foot control cable........................................................................H-3
1.5 Replacing the pedal assembly (new foot control model, from serial
number 826740)..........................................................................................H-4
1.6 Replacing pedal centering spring................................................................H-5
2 ADJUSTMENTS ............................................................................ H-7
2.1 Centering foot control pedal........................................................................H-7
2.2 Eliminating sideways play of the foot control pedal ....................................H-8
2.3 Adjusting tension and angle of the foot control pedal .................................H-9
2.4 Adjusting height of the foot control pedal (old foot control model, serial
number smaller than 826740)...................................................................H-10
2.5 Calibrating the sector plate and adjusting the angle of the foot control
pedal (new foot control model, from serial number 826740).....................H-11
2.6 Calibrating foot control ..............................................................................H-15
2.7 Adjustments and functional check-ups after parts replacements..............H-17
Chapter I DIAGRAMS

Planmeca Compact I Specifications

General

Spittoon	Yes
Operating Light	LED
Imaging Technology	Digital
X-ray Tube Voltage	60-70 kV
X-ray Tube Current	7 mA
Focal Spot Size	0.8 mm
Exposure Time Range	3.2 s
Power Supply	50/60 Hz
