9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
PART DESCRIPTION
TORQUE
SPECIFICATION
Coolant Surge Tank
Fasteners
2 lb-ft (2.7 Nm)
Intake Duct Hose Clamp 3 lb-ft (4 Nm)
Pulse Bar Fasteners
3 lb-ft (4 Nm)
CHAPTER 12 - CHASSIS / BODY ELECTRICAL
PART DESCRIPTION
TORQUE
SPECIFICATION
Battery Bracket 3.5 lb-ft (5 Nm)
Brake Switch
15 lb-ft (20 Nm)
Fuse Box Fasteners
35 lb-in (4 Nm)
Instrument Cluster
Mounting Bracket to
Vehicle Fasteners
3.5 lb-ft (4.7 Nm)
Instrument Cluster to
Mounting Bracket
Fasteners
30 lb-in (3.4 Nm)
Pulse Bar Bracket
Fasteners
60 in-lbs (7 Nm)
Pulse Bar Cable Nuts
24 in-lbs (3 Nm)
Pulse Bar Fasteners
Torque Until Fastener Is
Fully Seated
Speed Sensor 12 lb-ft (16 Nm)
Starter Motor Fasteners
7 lb-ft (10 Nm)
Tail Light Fasteners 4 lb-ft (5 Nm)
CHAPTER 13 - FACTORY-INSTALLED OPTIONS
PART DESCRIPTION
TORQUE
SPECIFICATION
AM/FM Antenna Ground
Strap Fastener
14 ft-lbs (19 Nm)
AM/FM Antenna Nut
25 in-lbs (3 Nm)
Amp Fasteners 30 in-lbs (4 Nm)
Audio Display Mounting
Fasteners
30 in-lbs (4 Nm)
Bumper Fasteners (Front) 30 lb-ft (41 Nm)
Front Speaker Cover
Fasteners
7 in-lbs (.75 Nm)
Front Speaker Housing
Mounting Fasteners
30 in-lbs (4 Nm)
Pulse Bar Cable Nuts
24 in-lbs (3 Nm)
PART DESCRIPTION
TORQUE
SPECIFICATION
Rear Camera Mount
Fasteners
5 ft-lbs (7 Nm)
Rear Speaker Mount
Bracket Fasteners
30 in-lbs (4 Nm
Rear View Mirror
Fasteners
5 lb-ft (7 Nm)
Ride Command Display
Fasteners
40 in-lbs (4.5 Nm)
Ride Command Display
Mount Fasteners
40 in-lbs (4.5 Nm)
Roof Mounting Bracket
Fasteners
8 lb-ft (11 Nm)
Side Mirror Mounting Nut lb-ft (Nm)
Speaker Fasteners 11 in-lbs (1.25 Nm)
Subwoofer / Amp Bracket
Fasteners
30 in-lbs (4 Nm)
Subwoofer Mounting
Fasteners
30 in-lbs (4 Nm)
Vehicle-to-Vehicle
Antenna Mounting /
Mount Bracket Fastener
40 in-lbs (4.5 Nm)
Vehicle-to-Vehicle
Antenna Slotted Nut
60 in-lbs (7 Nm)
Winch Contactor
Fasteners
6 ft-lbs (8 Nm)
Winch Fairlead Roller
Fasteners
30 lb-ft (41 Nm)
Winch Fasteners
16 lb-ft (22 Nm)
Winch Mounting Bracket 30 lb-ft (41 Nm)
