5.19
BODY / STEERING / SUSPENSION
5
9924096 - 2013 RANGER RZR XP 900 / RZR XP 4 900 Service Manual
© Copyright 2012 Polaris Sales Inc.
Chassis / Main Frame (RZR XP 4)
Bolt-In Brace /
Rear Bumper
Support
6.5 ft-lbs
(8.5 Nm)
Washers
Front Bumper
Support
Screws
17 ft-lbs
(23 Nm)
Screws
Front Cross Member
40 ft-lbs
(54 Nm)
Main Frame
Rear
38 ft-lbs
(52 Nm)
17 ft-lbs
(23 Nm)
Skid Plate
Front
Skid Plate
17 ft-lbs
(23 Nm)
Screws
Front Frame
