10.3
ELECTRICAL
10
9924096 - 2013 RANGER RZR XP 900 / RZR XP 4 900 Service Manual
© Copyright 2012 Polaris Sales Inc.
GENERAL INFORMATION
Special Tools
SPX Corp: 1-800-328-6657 or http://polaris.spx.com/
Electrical Service Notes
Keep the following notes in mind when diagnosing an
electrical problem:
• Refer to wiring diagram for stator and electrical
component resistance specifications.
• When measuring resistance of a component that
has a resistance value under 10 Ohms, remember
to subtract meter lead resistance from the reading.
Connect the leads together and record the
resistance. The resistance of the component is
equal to tested value minus the lead resistance.
• Become familiar with the operation of your meter.
Be sure leads are in the proper jack for the test
being performed (i.e. 10A jack for current
readings). Refer to the Owner’s Manual included
with your meter for more information.
• Voltage, amperage, and resistance values
included in this manual are obtained with a
Fluke™ 77 Digital Multimeter (PV-43568). This
meter is used when diagnosing electrical
problems. Readings obtained with other meters
may differ.
• Pay attention to the prefix on the multimeter
reading (K, M, etc.) and the position of the decimal
point.
• For resistance readings, isolate the component to
be tested. Disconnect it from the wiring harness or
power supply.
Under-Dash Components
The following switches and components can be accessed
underneath the instrument / dash panel:
• Speedometer
• Digital Wrench® Diagnostic Connector
•AWD Switch
• Headlamp Switch
• 12 Vdc Accessory Power Point
• Ignition Switch
• Fuse / Relay Box
Part Number Tool Description
PV-43568 Fluke™ 77 Digital Multimeter
PV-43526 Connector Test Kit
2870630 Timing Light
PU-50338 Battery Hydrometer
2460761 Hall Effect Sensor Probe Harness
2871745 Static Timing Light Harness
PU-50296
Battery Conductance Analyzer
(MDX-610P)
PU-49466 Relay Bypass
- Digital Wrench® (see Chapter 4)
