5.30
BODY / STEERING / SUSPENSION
9924096 - 2013 RANGER RZR XP 900 / RZR XP 4 900 Service Manual
© Copyright 2012 Polaris Sales Inc.
Upper Steering Shaft Removal (EPS Models)
1. Remove the (2) Torx-head fasteners retaining the
black plastic cover and remove the cover from the
vehicle.
2. Remove the pinch bolt retaining the upper steering
shaft to the power steering unit.
3. Remove the fastener retaining the upper portion of the
steering wheel tilt shock to the pivot tube. Swing the
shock down out of the way.
4. Lift the steering wheel up and remove the (2)
fasteners that retain the pivot tube.
5. Remove the steering shaft, pivot tube and steering
wheel from the vehicle as an assembly.
6. If replacing the upper steering shaft or steering wheel,
refer to “Steering Wheel Removal (EPS Models)”.
Remove
Remove
Remove as
an assembly
