10.26
ELECTRICAL
9924096 - 2013 RANGER RZR XP 900 / RZR XP 4 900 Service Manual
© Copyright 2012 Polaris Sales Inc.
Relay Operation
Located in the fuse box under the dash, the relays assist
with component operation like the cooling fan, fuel pump
and EFI system, drive system and EPS.
NOTE: The Rear Diff Solenoid Relay (INT’L) is
mounted separately, attached to the lower airbox
bracket, accessed through the right rear wheel well.
NOTE: The Headlight Relay (INT’L) and Flash to
Pass Relay (INT’L) are also mounted separately,
located under the dash.
CHASSIS RELAY provides power to the following
systems:
Lights (Headlights / Taillights)
Drive (AWD)
Accessory (12V Receptacles / Accessory Options)
EFI RELAY provides power to the following systems:
Fuel Injectors
Ignition Coil
Fan Relay
Fuel Pump Relay
FAN RELAY provides power to the following system:
•Fan Motor
FUEL PUMP RELAY provides power to the following
system:
•Fuel Pump
EPS RELAY (OPT) provides power to the following
system:
Electronic Power Steering Unit
Color Function
Red
30-Amp fuse protected 12 Vdc
constant battery voltage.
Brown Relay coil ground.
Orange
12 Vdc power input from key
switch to enable relay.
White
Provides 12 Vdc power for lights,
drive and accessory circuits.
Color Function
Red / White
20-Amp fuse protected 12 Vdc
constant battery voltage.
Dark Green / Yellow ECU ground input to enable relay.
Red / White
20-Amp fuse protected 12 Vdc
constant battery voltage.
Red / Dark Blue
Provides 12 Vdc power for EFI
system circuits.
Color Function
Red
20-Amp circuit breaker protected
12 Vdc constant battery power.
Orange / White ECU ground input to enable relay.
Red / Dark Blue
12 Vdc switched power from EFI
relay.
Orange / Black
Provides 12 Vdc power for fan
operation.
Color Function
Red / Green
10-Amp fuse protected 12 Vdc
battery voltage.
Dark Green / Yellow ECU ground input to enable relay.
Red / Dark Blue
12 Vdc switched power from EFI
relay.
Red / Blue
Provides 12 Vdc power for fuel
pump operation.
Color Function
Red
30-Amp fuse protected 12 Vdc
constant battery voltage.
Brown Relay coil ground.
Orange
12 Vdc power input from key
switch to enable relay.
Orange
Provides 12 Vdc power for EPS
operation.
