10.27
ELECTRICAL
10
9924096 - 2013 RANGER RZR XP 900 / RZR XP 4 900 Service Manual
© Copyright 2012 Polaris Sales Inc.
REAR DIFF SOLENOID RELAY (INT’L) provides power
to the following system:
• Rear Differential Solenoid
HEADLIGHT RELAY (INT’L) provides power to the
following system:
• Headlights
FLASH TO PASS RELAY (INT’L) provides power to the
following system:
• Momentary High Beam Headlight Operation
Color Function
Red / Dark Green
10-Amp fuse protected 12 Vdc
battery voltage.
Dark Green / White ECU input to enable relay.
Brown Relay coil ground.
Red
Relay switched power to operate
the Rear Diff Solenoid.
Blue
Ground to energize the Rear Diff
Solenoid.
Color Function
Red / Yellow
20-Amp fuse protected 12 Vdc
battery voltage.
White / Red Key switch input to enable relay.
Brown Relay coil ground.
Yellow / Dark Green
Relay switched power to operate
the Headlights.
Color Function
Dark Green
12 Vdc switched power from
headlight relay used to operate
low beam headlights during
“normally closed” relay operation.
Brown Relay coil ground.
Yellow
High beam input to “open” relay
and disable low beam headlights
in order to operate high beam
headlights momentarily.
Dark Green
“Normally closed” relay output to
operate low-beam headlights.
