8.41
TRANSMISSION
8
9924096 - 2013 RANGER RZR XP 900 / RZR XP 4 900 Service Manual
© Copyright 2012 Polaris Sales Inc.
Exploded View, Continued
Ref. Qty. Description Ref. Qty. Description
1. 1 Fill Plug 44. 1 Gear, Sector 16T
2. 1 Drain Plug, Magnetic 45. 1 Gear, Sector 31T
3. 14 Screw, M8 x 1.25 x 30 46. 1 Pawl, Detent
4. 6 Screw, M6 x 1 x 20 47. 1 Star, Detent
5. 3 Screw, M8 x 50 48. 1 Plate, Park, 12-Face
6. 1 Screw, M6 x 1 x 40 49. 1 Shaft, Output 53T
7. 6 Screw, M6 x 1 x 18 50. 1 Shaft, Idler 29T
8. 1 Nut, NyLoc, M8 x 1.25 51. 1 Shaft, Reverse 29T
9. 2 Washer, Cup 52. 1 Shaft, Front Output
10. 3 Washer 53. 1 Shaft, Input Helical
11. 1 Washer 54. 1 Bellcrank
12. 1 Washer 55. 1 Collar, Shift
13. 2 Pin, Dowel 56. 1 Rail, Shift Shaft
14. 1 Pin, Spring 57. 1 Tube, Vent, 1/4 in.
15. 1 Retaining Ring, External 58. 1 Shift Dog, Park
16. 1 Snap Ring 59. 1 Gear, 44T
17. 1 Retaining Ring, External 60. 2 Fork, Shift
18. 1 Retaining Ring, External 61. 1 Sprocket, 48T, 6-Face
19. 1 Retaining Ring, Internal 62. 1 Gear, Low 67T
20. 2 Retaining Ring, External 63. 1 Engagement Dog, 6-Face
21. 2 Retaining Ring, External 64. 1 Gear, 53T
22. 3 Retaining Ring, External 65. 1 Shaft, Pinion 11T
23. 1 Retaining Ring, External 66. 1 Gear, 46T
24. 2 Washer, Thrust 67. 1 Gear, Snorkel 13T
25. 1 Washer, Thrust 68. 1 Shaft, Shift
26. 1 Shim 69. 1 Weldment, Rear Mount Bracket
27. 1 Shim 70. 1 Bracket, Rear Mount
28. 2 Bearing, Needle Cage 71. 1 Cover, Bearing, Center Drive
29. 2 Bearing, Ball 72. 1 Spacer
30. 2 Bearing, Ball 73. 1 Chain, Silent
31. 2 Bearing, Ball 74. 1 Switch, Rotary, 2-Pin
32. 3 Bearing, Ball 75. 1 O-Ring
33. 1 Bearing, Needle Cage 76. 1 O-Ring
34. 1 Bearing, Ball 77. 1 O-Ring
35. 2 Bearing, Ball 78. 1 Seal, Triple Lip
36. 2 Spring, Compression 79. 1 Seal, Dual Lip
37. 2 Spring, Compression 80. 2 Seal, Triple Lip
38. 1 Spring, Compression, Detent 81. - N/A
39. 1 Tube, Snorkel 82. 1 Sensor, Speed
40. 1 Cover, Sector Gears 85. 1 Bearing, Ball
41. 1 Case, RH 86. 1 Spring, Wave
42. 1 Case, LH 88. 1 Bracket, Wire Harness
43. 1 Drum, Shift 89. 1 Collar Sleeve, Input Shaft
