TRANSMISSION
8
9924096 - 2013 RANGER RZR XP 900 / RZR XP 4 900 Service Manual
© Copyright 2012 Polaris Sales Inc.
Exploded View, Continued
Ref. Qty. Description Ref. Qty. Description
1. 1 Fill Plug 54. 1 Star, Detent
2. 1 Drain Plug, Magnetic 55. 1 Plate, Park, 12-Face
4. 14 Screw, M8 x 1.25 x 30 56. 1 Shaft, Idler 29T
5. 6 Screw, M6 x 1 x 20 57. 1 Shaft, Reverse 29T
6. 3 Screw, M8 x 50 58. 1 Shaft, Front Output
7. 1 Screw, M6 x 1 x 40 59. 1 Shaft, Input Helical
8. 6 Screw, M6 x 1 x 18 60. 1 Shaft, Pinion, 11T
9. 2 Screw, M6 x 1 x 16 61. 1 Disc, Brake
10. 1 Nut, NyLoc, M8 x 1.25 62. 1 Bellcrank
11. 2 Washer, Cup 63. 1 Collar, Shift
12. 1 Washer 64. 1 Rail, Shift Shaft
13. 3 Washer 65. 1 Tube, Vent, 1/4 in.
14. 1 Washer 66. 1 Fork, Pivot Shaft
15. 1 Washer 67. 1 Dog, Engagement
16. 2 Pin, Dowel 68. 1 Shift Dog, Park
17. 1 Pin, Spring 69. 1 Gear, 44T
18. 1 Retaining Ring, External 70. 2 Fork, Shift
19. 1 Snap Ring 71. 1 Sprocket, 48T, 6-Face
20. 1 Retaining Ring, External 72. 1 Gear, Low 67T
21. 1 Retaining Ring, External 73. 1 Engagement Dog, 6-Face
22. 1 Retaining Ring, Internal 74. 1 Gear, 53T
23. 2 Retaining Ring, External 75. 1 Gear, 46T
24. 2 Retaining Ring, External 76. 1 Gear, Snorkel 13T
25. 3 Retaining Ring, External 77. 1 Shaft, Shift
26. 1 Retaining Ring, External 78. 1 Weldment, Rear Mount Bracket
27. 2 Washer, Thrust 80. 2 Retainer, Fork
28. 1 Washer, Thrust 81. 1 Bracket, Rear Mount
29. 1 Shim 82. 1 Cover, Bearing, Center Drive
30. 1 Shim 83. 1 Spacer
31. 2 Bearing, Needle Cage 84. 1 Chain, Silent
32. 2 Bearing, Ball 85. 1 Solenoid
33. 1 Bearing, Ball 86. 1 Switch, Rotary, 2-Pin
34. 2 Bearing, Ball 87. 1 O-Ring
35. 3 Bearing, Ball 88. 1 O-Ring
36. 1 Bearing, Needle Cage 89. 1 O-Ring
37. 1 Bearing, Ball 90. 1 Seal, Triple Lip
38. 2 Bearing, Ball 91. 1 Seal, Triple Lip
39. 1 Bearing, Ball 92. 1 Seal, Dual Lip
40. 2 Spring, Compression 93. 2 Seal, Triple Lip
41. 2 Spring, Compression 95. 1 Sensor, Speed
42. 1 Spring, Torsion 98. 1 Bracket, Wire Harness
43. 1 Spring, Compression 99. 2 Plug, Expansion
44. 1 Spring, Compression, Detent 100. 1 Side Gear, Male, 39T
45. 1 Spring, Washer 101. 3 Bearing, Plain
46. 1 Tube, Snorkel 102. 1 Side Gear, Female, 39T
47. 1 Cover, Sector Gears 103. 1 Diff Cover
48. 1 Case, LH 104. 6 Planet Gear
49. 1 Case, RH 105. 7 Screw, M8 x 1.25 x 25
50. 1 Drum, Shift 106. 1 Ring Gear, 53T
51. 1 Gear, Sector 16T 108. 6 Bearing, Plain
52. 1 Gear, Sector 31T 109. 1 Collar Sleeve, Input Shaft
53. 1 Pawl, Detent
