9.2
BRAKES
9924096 - 2013 RANGER RZR XP 900 / RZR XP 4 900 Service Manual
© Copyright 2012 Polaris Sales Inc.
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS SPECIAL TOOLS
SPX Corp: 1-800-328-6657 or http://polaris.spx.com/
FRONT BRAKE SYSTEM
Item Standard Service Limit
Front Brake Pad Thickness .297 ± .007" (7.54 ± .178 mm) .180" (4.6 mm)
Front Brake Disc Thickness .188" (4.78 mm) .170" (4.32 mm)
Front Brake Disc Runout - .010" (.254 mm)
REAR BRAKE SYSTEM
Item Standard Service Limit
Rear Brake Pad Thickness .298 ± .007" (7.57 ± .178 mm) .180" (4.6 mm)
Rear Brake Disc Thickness .188" (4.78 mm) .170" (4.32 mm)
Rear Brake Disc Runout - .010" (.254 mm)
PARK BRAKE SYSTEM (INT’L MODEL)
Item Standard Service Limit
Park Brake Pad Thickness
Inboard - 0.300” (7.62 mm) 0.240” (6.10 mm)
Outboard - 0.250” (6.35 mm) 0.190" (4.83 mm)
Park Brake Disc Thickness 0.175” - 0.185” (4.44 - 4.70 mm) 0.150" (3.81 mm)
Item
Torque
ft-lbs
Torque
Nm
Front Caliper Mounting Bolts 40 54
Rear Caliper Mounting Bolts 40 54
Brake Line Flare 12-15 16-20
Brake Line Banjo Bolts
(Caliper Attachment)
15 20
Brake Line Banjo Bolt
(Master Cylinder Attachment)
15 20
Brake Switch 15 20
Brake Disc to Hub Bolts 30 41
Master Cylinder to Frame 23 31
Brake Pedal Mounting Bracket
to Frame
16 22
Park Brake Assembly Bolts 37 50
Park Brake Disc Mounting Bolt 18-22 24-30
Park Brake Lever Mount Bolts 16 22
Park Brake Mount Bracket to
Transmission Bolts
37 50
Part Number Tool Description
2870975 Mity Vac™ Pressure Test Tool
