Quantum Scalar i80 User Manual

Chapter 3: Understanding the User Interface
Operator Panel
Quantum Scalar i40 and Scalar i80 User’s Guide 25
Status The status field displays the current state or
operation being performed by the robot. If the
robot is not idle, the status will blink. status can
be any of the following:
• Initializing — The is currently in the process of
initializing.
• Autoleveling — The robotics hardware is being
autoleveled.
• Homing — The robot is performing a home
operation.
• Teaching — The robot is performing a teach
operation.
• Calibrating — The robot is performing a
calibration operation.
• Scanning — The robot is performing an
inventory operation.
• Unlocking — The robot is in the process of
unlocking a magazine.
• Move Media — The robot is moving media
from one location to another.
• Loading — The robot is in the process of
moving a tape to load into a tape drive.
• Unloading — The robot is in the process of
unloading a tape drive and returning it to the
source location.
• Idle — The robot is ready and idle.
• Not Ready — The robotics system is not ready.
Operator Panel
Element Description

Quantum Scalar i80 Specifications

General

Power supply type	AC
Power requirements	100 – 240V, 50/60Hz
Power consumption (typical)	200 W
Dimensions (WxDxH)	445 x 793 x 264 mm
Media types supported	2x LTO-4
Maximum supported storage capacity	128 TB
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Form factor	6U
Product type	Storage auto loader & library
Certification	IEC 60950, Class A / FCC part 15, ICES-003, CISPR 22, EN55022 Class A, VCCI, CNS 13438, KN22, AS/NZS CISPR 22, EN61000-3-2, EN61000-3-3 EN55024, KN24 CE, VCCI, GS, FCC, ICES, NRTL, GOST, BSMI, KCC
Product color	Black
Standard interfaces	Fiber Channel

Weight and Dimensions

Weight	23800 g
