Quantum Scalar i80 - Figure 42 Connection Locations

Chapter 9: Installing, Removing, and Replacing Components
Connecting Library Cables
228 Quantum Scalar i40 and Scalar i80 User’s Guide
Figure 42 Connection
Locations
Ethernet cable in
LEFT SCB port
Tape drive cables
Filler plate
Power supply cord
Service port – do not use
Filler plate
Full-height tape drives
Ethernet cable in
LEFT SCB port
Tape drive cables
Power supply cord
Service port –
do not use
Filler plate
Half-height tape drives
