Chapter 3: Understanding the User Interface
Web Client
Quantum Scalar i40 and Scalar i80 User’s Guide 31
Table 3 Web Client Screen
Elements
Web Client
Element Description
Header The header is present on all pages and contains
the library typ
e (Scalar i40 or Scalar i80) and three
buttons:
Home — Brings you to the home page.
Help — Displays the online help.
Logout — Logs out of the current session.
A message in the header alerts you when the
robot i
s not ready to perform library functions.
See
Troubleshooting Library “Not Ready”
Messages on page 318 for more information on
“Library Not Ready” messages di
splayed in the
header.
Menu bar Displays the available menu
choices. The choices
vary depending on login privileges.
The far right of the menu bar also displays the
name
of the logged-in user, with the associated
privilege level indicated in brackets.
If a menu item selected has a sub-menu, then >
is
displayed to the right of the item.
Active display The active display provides information or menu
ite
ms according to the selected menu item or
operation.
Web Client Home Page The home page displays status and health information in the active
display portion of the window (see Figure
11 on page 30). See System
Summary and Subsystem Status below for more information.
System Summary The system summary is available on the home page of the Web client.
