Appendix A: Specifications
Power Consumption and Heat Output
Quantum Scalar i40 and Scalar i80 User’s Guide 345
Power Consumption and Heat Output
Typical library power consumption (watts/hour) and heat output (BTU/
hour) are listed below. The values listed below are average (not peak or
maximum) values.
Component
Typical Power
Co
nsumption
(Watts/Hour)
Typical Heat
Output (BTU/
Hour)
Scalar i40 library minimum configuration:
no tape drives installed; random robot movement
18 61
Scalar i40 library maximum configuration:
two (2) tape drives*, writing
70 239
Scalar i80 library minimum configuration:
no tape drives installed; one power supply, random
robot movement
18 61
Scalar i80 library maximum configuration:
five (5) tape drives*, writing, two power supp
lies
159 544
HP LTO-4 tape drive*, writing, one power supply,
no robot movement
24 82
HP LTO-5 tape drive*, writing, one power supply,
no robot movement
27 92
Second power supply, Scalar i80 7 24
* The difference in power consumption and heat output between full-height and half height tape drives, and
between Fibre Channel and SAS tape drives, is negligible.

Quantum Scalar i80 Specifications

General

Power supply type	AC
Power requirements	100 – 240V, 50/60Hz
Power consumption (typical)	200 W
Dimensions (WxDxH)	445 x 793 x 264 mm
Media types supported	2x LTO-4
Maximum supported storage capacity	128 TB
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Form factor	6U
Product type	Storage auto loader & library
Certification	IEC 60950, Class A / FCC part 15, ICES-003, CISPR 22, EN55022 Class A, VCCI, CNS 13438, KN22, AS/NZS CISPR 22, EN61000-3-2, EN61000-3-3 EN55024, KN24 CE, VCCI, GS, FCC, ICES, NRTL, GOST, BSMI, KCC
Product color	Black
Standard interfaces	Fiber Channel

Weight and Dimensions

Weight	23800 g
