Chapter 9: Installing, Removing, and Replacing Components
Packaging the Library for Moving or Shipping
296 Quantum Scalar i40 and Scalar i80 User’s Guide
13 Wrap the library in the anti-static wrapping provided in the
packaging kit.
WARNING: Two people are required to safely lift the library.
14 Place the library in the packaging as shown in Figure 74 and
Figure
75.
Figure 74 Scalar i40 Packaging
To p f o a m
Library (anti-static
wrap not shown
for clarity)
Bottom foam
Shipping carton
