Quantum Scalar i80 User Manual

Chapter 5: Advanced Reporting
Working with Control Path Failover (CPF)
Quantum Scalar i40 and Scalar i80 User’s Guide 117
Figure 18 Force CPF Screen
3 Select the partition on which you want to force the failover, and
click Apply.
Note: The standby tape drive must be “ready” and “connected”
in order to force a failover.
4 Click Apply.
The new active tape drive lo
cation displays in the Active Drive
column. The new standby tape drive location displays in the
Standby Drive column.
Note: If the new tape drive locations do not display, refresh the
browser.
Active Connected Whether the current control path tape drive
is connected and has a working link.
Standby Drive Location of the standby tape drive.
Standby Status Ready status of the standby tape drive.
Standby
Co
nnected
Whether the standby tape drive is
connected and has a working link.
Column Indicates

Quantum Scalar i80 Specifications

General

Power supply type	AC
Power requirements	100 – 240V, 50/60Hz
Power consumption (typical)	200 W
Dimensions (WxDxH)	445 x 793 x 264 mm
Media types supported	2x LTO-4
Maximum supported storage capacity	128 TB
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Form factor	6U
Product type	Storage auto loader & library
Certification	IEC 60950, Class A / FCC part 15, ICES-003, CISPR 22, EN55022 Class A, VCCI, CNS 13438, KN22, AS/NZS CISPR 22, EN61000-3-2, EN61000-3-3 EN55024, KN24 CE, VCCI, GS, FCC, ICES, NRTL, GOST, BSMI, KCC
Product color	Black
Standard interfaces	Fiber Channel

Weight and Dimensions

Weight	23800 g
