Chapter 9: Installing, Removing, and Replacing Components
Installing the Library in a Desktop Kit
244 Quantum Scalar i40 and Scalar i80 User’s Guide
4 Remove all the tape drives from the library (for details, see
Removing and Replacing a Tape Drive on page 286).
5 Remove all the magazines from the library (for details, see Removing
and Replacing a Magazine on page 271).
6 Unscrew the captive thumbscrews in the “rack ears” that secure the
library to the rack (see
Figure 51 on page 243).
7 Slide the library out of the rack. Keep the library level as you slide it
out of the rack.
8 Place the library on a flat, stable surface.
Installing the Library in a Desktop Kit
The instructions for installing the Scalar i40 and the Scalar i80 in a
desktop are the same. The only difference is that the Scalar i40 has two
side panels, and the Scalar i80 has four.

Quantum Scalar i80 Specifications

General

Power supply type	AC
Power requirements	100 – 240V, 50/60Hz
Power consumption (typical)	200 W
Dimensions (WxDxH)	445 x 793 x 264 mm
Media types supported	2x LTO-4
Maximum supported storage capacity	128 TB
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Form factor	6U
Product type	Storage auto loader & library
Certification	IEC 60950, Class A / FCC part 15, ICES-003, CISPR 22, EN55022 Class A, VCCI, CNS 13438, KN22, AS/NZS CISPR 22, EN61000-3-2, EN61000-3-3 EN55024, KN24 CE, VCCI, GS, FCC, ICES, NRTL, GOST, BSMI, KCC
Product color	Black
Standard interfaces	Fiber Channel

Weight and Dimensions

Weight	23800 g
