Quantum Scalar i80 User Manual

Chapter 9: Installing, Removing, and Replacing Components
Installing the Rack Mount Kit (Rail Kit)
232 Quantum Scalar i40 and Scalar i80 User’s Guide
Installing the Rack
Mount Shelves
Before installing the rack mount shelves, you must collect the following
information:
• Type of rack mount rails (square hole, through hole, or threaded
hole)
•Depth of rack
1 Assemble the rack mount shelves included in the accessory kit (left
and right):
a The holes used to attach the two halves of the rack mount
shelves differ depending on the depth of the rack (see
Figure 43
on page 233). It is recommended that you use the ones that are
exposed and have the widest spacing.

Quantum Scalar i80 Specifications

General

Power supply type	AC
Power requirements	100 – 240V, 50/60Hz
Power consumption (typical)	200 W
Dimensions (WxDxH)	445 x 793 x 264 mm
Media types supported	2x LTO-4
Maximum supported storage capacity	128 TB
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Form factor	6U
Product type	Storage auto loader & library
Certification	IEC 60950, Class A / FCC part 15, ICES-003, CISPR 22, EN55022 Class A, VCCI, CNS 13438, KN22, AS/NZS CISPR 22, EN61000-3-2, EN61000-3-3 EN55024, KN24 CE, VCCI, GS, FCC, ICES, NRTL, GOST, BSMI, KCC
Product color	Black
Standard interfaces	Fiber Channel

Weight and Dimensions

Weight	23800 g
