Quantum Scalar i80 User Manual

Chapter 9: Installing, Removing, and Replacing Components
Installing the Rack Mount Kit (Rail Kit)
Quantum Scalar i40 and Scalar i80 User’s Guide 231
8 T- nut (M5) – for shelf assembly
8 total
Rail adapter – 4 each of two types are included. You
need 4 for installation; choose the type appropriate
for your rack (for more information, see Figure
45
on page 235)
8
Phillips head screw, countersunk (M4 x 12) – for
mounting shelves to rack
8
Washer, countersunk – for mounting shelves to rack
4
Clip nut (M5 x 0.8) – for securing library in rack
4
Cage nut (M5) – to secure library to rack. Used in
racks with square or round non-threaded holes.
Qty Figure Description

Quantum Scalar i80 Specifications

General

Power supply type	AC
Power requirements	100 – 240V, 50/60Hz
Power consumption (typical)	200 W
Dimensions (WxDxH)	445 x 793 x 264 mm
Media types supported	2x LTO-4
Maximum supported storage capacity	128 TB
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Form factor	6U
Product type	Storage auto loader & library
Certification	IEC 60950, Class A / FCC part 15, ICES-003, CISPR 22, EN55022 Class A, VCCI, CNS 13438, KN22, AS/NZS CISPR 22, EN61000-3-2, EN61000-3-3 EN55024, KN24 CE, VCCI, GS, FCC, ICES, NRTL, GOST, BSMI, KCC
Product color	Black
Standard interfaces	Fiber Channel

Weight and Dimensions

Weight	23800 g
