Quantum Scalar i80 User Manual

Chapter 9: Installing, Removing, and Replacing Components
Installing the Rack Mount Kit (Rail Kit)
230 Quantum Scalar i40 and Scalar i80 User’s Guide
Space Requirements See the following:
•
Physical Specifications on page 341 and
•
Air Clearance Requirements on page 343
Tools Required • Phillips screwdriver
• Magazine lock override tool — an op
ened paperclip, small
screwdriver, or other object (3.5 mm or less in diameter that will not
break off)
Rack Mount Kit
Contents
The following items are included in the rack mount kit:
Qty Figure Description
2
Shelf
2
Shelf Extender
16
Phillips head screw, countersunk (M5 x 10) – for
shelf assembly

Quantum Scalar i80 Specifications

General

Power supply type	AC
Power requirements	100 – 240V, 50/60Hz
Power consumption (typical)	200 W
Dimensions (WxDxH)	445 x 793 x 264 mm
Media types supported	2x LTO-4
Maximum supported storage capacity	128 TB
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Form factor	6U
Product type	Storage auto loader & library
Certification	IEC 60950, Class A / FCC part 15, ICES-003, CISPR 22, EN55022 Class A, VCCI, CNS 13438, KN22, AS/NZS CISPR 22, EN61000-3-2, EN61000-3-3 EN55024, KN24 CE, VCCI, GS, FCC, ICES, NRTL, GOST, BSMI, KCC
Product color	Black
Standard interfaces	Fiber Channel

Weight and Dimensions

Weight	23800 g
