Quantum Scalar i80 User Manual

Chapter 5: Advanced Reporting
Working with Control Path Failover (CPF)
114 Quantum Scalar i40 and Scalar i80 User’s Guide
When control path failover is configured for a partition, the partition
uses a virtual port as the control path communication port. The World
Wide Port Name (WWPN) for this virtual port is listed in the library’s
System Information Report in the Library Partitions section under
Control Path (see
Viewing System Information on page 206).
Configuring CPF You can configure control path failover from the Web client only.
Web Client
1 Setup the drive topology.
Set the topology for the control path
and control path failover tape
drives to Point to Point. For more information, refer to
Configuring
Tap e Dr iv e Pa r am et ers on page 65.
a Selec
t Setup > Drive Settings.
The Setup
- Drive Settings screen displays.
Figure 15 Setup - Drive
Settings Screen
b For the appropriate partition, select the Requested Topology of
Point to Point from the drop down menu.
c Cl
ick Apply.

Quantum Scalar i80 Specifications

General

Power supply type	AC
Power requirements	100 – 240V, 50/60Hz
Power consumption (typical)	200 W
Dimensions (WxDxH)	445 x 793 x 264 mm
Media types supported	2x LTO-4
Maximum supported storage capacity	128 TB
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Form factor	6U
Product type	Storage auto loader & library
Certification	IEC 60950, Class A / FCC part 15, ICES-003, CISPR 22, EN55022 Class A, VCCI, CNS 13438, KN22, AS/NZS CISPR 22, EN61000-3-2, EN61000-3-3 EN55024, KN24 CE, VCCI, GS, FCC, ICES, NRTL, GOST, BSMI, KCC
Product color	Black
Standard interfaces	Fiber Channel

Weight and Dimensions

Weight	23800 g
