Chapter 9: Installing, Removing, and Replacing Components
Installing the Library in a Desktop Kit
Quantum Scalar i40 and Scalar i80 User’s Guide 251
Figure 55 Installing side panels
Hole for captive
thumbscrew
Captive
thumbscrew
Holes for side
panel posts
Magazine release
access holes
Inset showing captive thumbscrew behind open magazine
