Quantum Scalar i40 and Scalar i80 User’s Guide 341
Appendix A
Specifications
Physical Specifications
Ta b l e 7 Base Library
Scalar i40 Scalar i80
Height 5.2 in. (132 mm) 10.4 in. (264 mm)
Width (excluding
“rack ears”) 17.5 in. (445 mm) 17.5 (445 mm)
Depth (from library
front bezel to back
of library; excluding drive sleds)*
31.2 in. (793 mm) 31.2 in. (793 mm)
Weight (one p
ower supply, no tape
drives, and no tape cartridges installed)
34.9 lbs. (15.8kg) 52.4 lbs. (23.8 kg)
Weight (one
power supply, two tape
drives, and no tape cartridges installed)
With 2 half-height SAS tape
drives: 44.2 lbs. (20 kg)
With 2 full-height SAS tape
drives: 65.7 lbs. (29.8 kg)
* Depths listed above exclude drive sleds. Drive sleds will add up to 50 mm to the overall length of the library
depending on tape drive type (half-height, full-height, Fibre Channel, SAS). Additionally, when planning space
requirements, take into account installed cables (particularly fibre-optic cable radius on Fibre Channel tape drives).

Quantum Scalar i80 Specifications

General

Power supply type	AC
Power requirements	100 – 240V, 50/60Hz
Power consumption (typical)	200 W
Dimensions (WxDxH)	445 x 793 x 264 mm
Media types supported	2x LTO-4
Maximum supported storage capacity	128 TB
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Form factor	6U
Product type	Storage auto loader & library
Certification	IEC 60950, Class A / FCC part 15, ICES-003, CISPR 22, EN55022 Class A, VCCI, CNS 13438, KN22, AS/NZS CISPR 22, EN61000-3-2, EN61000-3-3 EN55024, KN24 CE, VCCI, GS, FCC, ICES, NRTL, GOST, BSMI, KCC
Product color	Black
Standard interfaces	Fiber Channel

Weight and Dimensions

Weight	23800 g
