Quantum Scalar i80 User Manual

Chapter 9: Installing, Removing, and Replacing Components
Replacing the Chassis
264 Quantum Scalar i40 and Scalar i80 User’s Guide
Figure 62 Restraining the Y-
tray
Four Y-tray restraint
thumbscrews
Rack “ear” overhangs
edge of desk or table
11 If desired, you may cover the holes in the replacement library top
cover with stickers, which are provided in the accessory kit for this
purpose. This step is optional and is intended to prevent small
objects from accidentally falling into the library through the holes.
12 Install
the new chassis in a rack or desktop kit. For instructions, see
Installing the Rack Mount Kit (Rail Kit) on page 229 or Installing the
Library in a Desktop Kit on page 244.
WARNING: Two people are required to safely lift the library.

Quantum Scalar i80 Specifications

General

Power supply type	AC
Power requirements	100 – 240V, 50/60Hz
Power consumption (typical)	200 W
Dimensions (WxDxH)	445 x 793 x 264 mm
Media types supported	2x LTO-4
Maximum supported storage capacity	128 TB
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Form factor	6U
Product type	Storage auto loader & library
Certification	IEC 60950, Class A / FCC part 15, ICES-003, CISPR 22, EN55022 Class A, VCCI, CNS 13438, KN22, AS/NZS CISPR 22, EN61000-3-2, EN61000-3-3 EN55024, KN24 CE, VCCI, GS, FCC, ICES, NRTL, GOST, BSMI, KCC
Product color	Black
Standard interfaces	Fiber Channel

Weight and Dimensions

Weight	23800 g
