Chapter 9: Installing, Removing, and Replacing Components
Replacing the Chassis
Quantum Scalar i40 and Scalar i80 User’s Guide 265
13 Install the components you removed from the old chassis into the
new chassis.
Component to
Install
Instructions
System Control
Board (SCB)
Install the SCB before you install the power supply.
1 Position the SCB for installation: The board components face up. The flat
part of the board faces down. The thumbscrews are on the upper side of
the SCB back plate.
2 Install the new SCB by pushing the SCB into the slot until it stops. It should
slide smoothly and easily. When it reaches the end of its travel, press firmly
on the back panel of the SCB to “snap” it into place.
3 Tighten the two thumbscrews finger tight.
4 Connect the Ethernet cable to the LEFT Ethernet port (as viewed from the
back of the library; see
Figure 63 on page 267).
Power Supplies If your library is a Scalar i80 and you have only one power supply, install it in
the top slot. If you have two power supplies, install them both.
Caution: Make sure the power supply is unplugged and disconnected from
live power before you install it.
1 Push the power supply straight into the slot. You may need to press firmly
on the power supply sheet metal at the very end to plug in the power
supply to the connector on the library. You will feel it snap into place.
The power supply only goes in one way, and should slide in easily. If you
cannot slide it in, you may be trying to install it upside down.
2 Tighten the two thumbscrews finger tight.
3 Connect the power cord to the power supply.
4 Plug the power cord into a grounded AC outlet.

Quantum Scalar i80 Specifications

General

Power supply type	AC
Power requirements	100 – 240V, 50/60Hz
Power consumption (typical)	200 W
Dimensions (WxDxH)	445 x 793 x 264 mm
Media types supported	2x LTO-4
Maximum supported storage capacity	128 TB
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Form factor	6U
Product type	Storage auto loader & library
Certification	IEC 60950, Class A / FCC part 15, ICES-003, CISPR 22, EN55022 Class A, VCCI, CNS 13438, KN22, AS/NZS CISPR 22, EN61000-3-2, EN61000-3-3 EN55024, KN24 CE, VCCI, GS, FCC, ICES, NRTL, GOST, BSMI, KCC
Product color	Black
Standard interfaces	Fiber Channel

Weight and Dimensions

Weight	23800 g
