Table 2.27 Single Data Transfer Instructions
Instruction Instruction Code Operation
Execution
States DC
MOVS.W @-As,Ds 111101AADDDD0000 As – 2 → As, (As) →
MSW of Ds, 0 → LSW of Ds
1 
MOVS.W @As,Ds 111101AADDDD0100 (As) → MSW of Ds,
0 → LSW of Ds
1 
MOVS.W @As+,Ds 111101AADDDD1000 (As) → MSW of Ds,
0 → LSW of Ds, As + 2 → As
1 
MOVS.W @As+Is,Ds 111101AADDDD1100 (Asc) → MSW of Ds,
0 → LSW of Ds, As + Is → As
1 
MOVS.W Ds,@-As* 111101AADDDD0001 As – 2 → As,
MSW of Ds → (As)
1 
MOVS.W Ds,@As* 111101AADDDD0101 MSW of Ds → (As) 1 
MOVS.W Ds,@As+* 111101AADDDD1001 MSW of Ds → (As),
As + 2 → As
1 
MOVS.W Ds,@As+Is* 111101AADDDD1101 MSW of Ds → (As),
As + Is → As
1 
MOVS.L @-As,Ds 111101AADDDD0010 As – 4 → As, (As) → Ds 1 
MOVS.L @As,Ds 111101AADDDD0110 (As) → Ds 1 
MOVS.L @As+,Ds 111101AADDDD1010 (As) → Ds, As + 4 → As 1 
MOVS.L @As+Is,Ds 111101AADDDD1110 (As) → Ds, As + Is → As 1 
MOVS.L Ds,@-As 111101AADDDD0011 As – 4 → As, Ds → (As) 1 
MOVS.L Ds,@As 111101AADDDD0111 Ds → (As) 1 
MOVS.L Ds,@As+ 111101AADDDD1011 Ds → (As), As + 4 → As 1 
MOVS.L Ds,@As+Is 111101AADDDD1111 Ds → (As), As + Is → As 1 
Note: * If guard bit registers A0G and A1G are specified in source operand Ds, the data is
output to the LDB[7:0] bus and the sign bit is copied into the upper bits, [31:8].
