Renesas HD6417641 - Bus Cycle of Byte-Selection SRAM; Figure 25.20 Byte-Selection SRAM Bus Cycle (SW = 1 Cycle, HW = 1 Cycle, One Asynchronous External Wait Cycle, BAS = 0 (Write Cycle UB;LB Control))

To Next Page

To Previous Page

Section 25 Electrical Characteristics

Rev. 4.00 Sep. 14, 2005 Page 932 of 982

REJ09B0023-0400

25.3.5 Bus Cycle of Byte-Selection SRAM

AD1

RSD

RDS1

CSD1

RWD1

T1 Twx T2 Tf

WDD1

BSD

WDH1

RDH1

AD1

CSD1

CKIO

A25 to A0

CSn

WEn

D31 to D0

Read

RD/WR

WAIT

Write

DACD

BSD

WTS1

RWD1

WED1

WTH1

DACKn,

TENDn*

Note: * Waveform for DACKn and TENDn when active low is selected.

Figure 25.20 Byte-Selection SRAM Bus Cycle (SW = 1 Cycle, HW = 1 Cycle, One

Asynchronous External Wait Cycle, BAS = 0 (Write Cycle UB/LB Control))
