Section 18 Multi-Function Timer Pulse Unit (MTU)
Rev. 4.00 Sep. 14, 2005 Page 527 of 982
REJ09B0023-0400
Table 18.7 TPSC0 to TPSC2 (Channel 2)
Channel
Bit 2
TPSC2
Bit 1
TPSC1
Bit 0
TPSC0
Description
2 0 0 0 Internal clock: counts on Pφ/1
1 Internal clock: counts on Pφ/4
1 0 Internal clock: counts on Pφ/16
1 Internal clock: counts on Pφ/64
1 0 0 External clock: counts on TCLKA pin input
1 External clock: counts on TCLKB pin input
1 0 External clock: counts on TCLKC pin input
1 Internal clock: counts on Pφ/1024
Note: This setting is ignored when channel 2 is in phase counting mode.
Table 18.8 TPSC0 to TPSC2 (Channels 3 and 4)
Channel
Bit 2
TPSC2
Bit 1
TPSC1
Bit 0
TPSC0
Description
3, 4 0 0 0 Internal clock: counts on Pφ/1
1 Internal clock: counts on Pφ/4
1 0 Internal clock: counts on Pφ/16
1 Internal clock: counts on Pφ/64
1 0 0 Internal clock: counts on Pφ/256
1 Internal clock: counts on Pφ/1024
1 0 External clock: counts on TCLKA pin input
1 External clock: counts on TCLKB pin input
