3.
The 2nd registration sensor (
x 1,
x 3).
Air Purge Detection Switch
Preparation:
•
Duplex unit (J028/J029/J035) (
page 48).
•
Rear cover (
page 51 "Rear Cover, Top Cover").
•
Top cover (
page 51 "Rear Cover, Top Cover").
•
Right cover (
page 53).
•
Unlock the carriage (
page 62).
Sensors, Switches
107
108
110
