Use this SP to display the current count for the number of times the status of the Ink
Collector unit has changed from near-full to full.
Note: The full threshold is 3 ml.
Display Full Count for Right Ink Sump
7-003-002 WASTE CNT:RF:FUL Right Ink Sump Full Count
This SP code displays the full count for the right ink sump.
Display Count: Mist Counter for Automatic Cleaning
7-003-003 MIST CNT:T1 Print Head Tank 1 (Cyan)
7-003-004 MIST CNT:T2 Print Head Tank 2 (Black)
7-003-005 MIST CNT:T3 Print Head Tank 3 (Yellow)
7-003-006 MIST CNT:T4 Print Head Tank 4 (Magenta)
Use this SP to display the number of times that the swing plate of the left Ink
Collector unit has made contact with the carriage.
Display Count: Paper Dust Counter for Automatic Cleaning
7-003-009 FEED CNT:H1 Print Head 1 (C / K)
7-003-010 FEED CNT:H2 Print Head 2 (Y / M)
Use this SP to display the current reading of the ink mist counter that determines
when to execute automatic cleaning.
Display Count: Cap Off Time for Automatic Print Head Cleaning
7-003-013 DECAP TIME
Use this SP to display the de-capping time used to determine whether automatic
cleaning is executed after the printer returns from idle mode.
2. Appendix: SP Mode Tables
70
