Set Print Head Rank (Voltage)
3-002-005 HRANK:H1:V Print Head 1
3-002-006 HRANK:H2:V Print Head 2
Use this SP to set the print head rank (voltage rank)
[0 to 7/FA/1/---]
DAC Adjustment Value
3-004-001 DAC:Y1:B Y1 Down Position
3-004-002 DAC:Y1:T Y1 Up Position
3-004-003 DAC:Y2:B Y2 Down Position
3-004-004 DAC:Y2:T Y2 Up Position
DFU
3-004-005 DAC:C1 C1
3-004-006 DAC:C2 C2
3-004-007 DAC:X1 X1
3-004-008 DAC:X2 X2
3-004-009 DAC:C3 C3
DFU
Ink Consumption in the Print Cartridge
3-005-001 C:INKCONSUME:T1 Print Head Tank 1 (Cyan)
3-005-002 C:INKCONSUME:T2 Print Head Tank 2 (Black)
3-005-003 C:INKCONSUME:T3 Print Head Tank 3 (Yellow)
3-005-004 C:INKCONSUME:T4 Print Head Tank 4 (Magenta)
Use this SP to check the ink consumption counter.
SP Mode Service Tables
49
