Ricoh Aficio SG 3100DN - Hvps

• There are two types of PSU. Before mounting the PSU, check the voltage indicated on the board.
•
100V : For NA
• 200V : For EU, ASIA
HVPS
Preparation:
•
Duplex unit (J028/J029/J035) (
page 48).
•
Canopy cover (
page 56).
•
Top cover (
page 51 "Rear Cover, Top Cover").
•
Rear Cover (
page 51 "Rear Cover, Top Cover").
•
Left Cover (
page 55).
•
Feed clutch (
page 95).
•
Vertical motor (
page 91).
•
Vertical encoder wheel (
page 69).
Boards
79
