Rear Cover
1. Engage the tabs on the rear cover in the brim of the machine's frame and attach the rear cover.
2. After attaching the rear cover, check that the tabs [A] on the top left and top right are engaged.
Unlocking, Moving the Carriage
Many maintenance and some cleaning procedures require that you unlock the carriage and push it
completely to the left side or center of the printer. Follow this procedure whenever you are instructed to
unlock the carriage.
1. The right cover ( page 53).
4. Replacement and Adjustment
