Right Front Cover Switch
Preparation:
• Duplex unit (J028/J029/J035) ( page 48).
• All covers ( page 50).
• Maintenance unit ( page 64).
• Right ink sump ( page 67).
• All ink cartridges.
• Unlock the carriage ( page 62).
1. Push the carriage to the left side of the machine.
2. Three screws ( x 3).
3. Three connectors ( x 3, x 1).
4. Replacement and Adjustment
110
